Product Model
ms4-wpm-d
Key Features
- 1The MS4-WPM-D mounting bracket features a corrosion resistance classification of CRC 2, suitable for moderate corrosion stress.
- 2This mounting bracket operates within a medium temperature range of -10°C to 60°C, making it versatile for various applications.
- 3Made from die-cast aluminum, steel screws, and NBR seals, the MS4-WPM-D ensures durability and reliability.
- 4Weighing 45 grams and measuring 4 in size, this mounting bracket is compact and lightweight.
- 5The MS4-WPM-D conforms to RoHS standards, ensuring it is free of copper and PTFE, making it an environmentally friendly choice.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 4 | Series | MS |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | -10°C 60°C | Product weight | 45g |
| Note on materials | RoHS-compliant | Seals material | NBR |
| Module connector material | POM Steel | Material of screws | Steel |
| Bracket material | Die-cast aluminum | Manufacturer ID | 526060 |
Specifications may be subject to change without notice
