Product Model
ysrw-5-8
Key Features
- 1The YSRW-5-8 shock absorber offers self-adjusting cushioning, ensuring optimal performance in various operating conditions.
- 2With a soft characteristic curve, this shock absorber provides smooth and controlled deceleration, reducing impact forces.
- 3Classified as CRC 2, the YSRW-5-8 has moderate corrosion resistance, making it suitable for applications in moderate corrosive environments.
- 4Available for optional mounting positions, this shock absorber can be easily integrated into various systems.
- 5Weighing only 8 grams, the YSRW-5-8 is a compact and lightweight solution for applications requiring precise cushioning.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 5 | Stroke | 8mm |
| Cushioning | Self-adjusting Soft characteristic curve | Mounting position | Any |
| Position sensing | None | Symbol | 00991495 |
| Max. impact velocity | 2m/s | Reset time at room temperature | 0.2s |
| Reset time at min. ambient temperature | 1s | Mode of operation | Pushing Single-acting |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10°C 80°C | Cushioning length | 8mm |
| Max. stop force | 200N | Max. energy absorption per stroke | 1.3J |
| Max. energy absorption per hour | 10000J | Max. residual energy | 0.01J |
| Resetting force | 0.9N | Min. insertion force | 7.5N |
| Product weight | 8g | Load range | 2kg |
| Type of mounting | With lock nut | Note on materials | RoHS-compliant |
| Seals material | NBR | Housing material | High-alloy steel |
| Piston rod material | High-alloy steel | Manufacturer ID | 191192 |
Specifications may be subject to change without notice
