Product Model
vas-30-1/8-si-b

Key Features
- 1The Festo VAS-30-1/8-SI-B is a high-precision valve designed for precise control in various automation applications. Its robust construction ensures reliable performance under demanding conditions.
- 2This valve features a compact design with a 1/8-inch port size, making it ideal for applications requiring precise flow regulation and minimal space usage.
- 3The VAS-30-1/8-SI-B is part of Festo's extensive range of automation components, offering users a single-source solution for all their pneumatic and electrical needs.
- 4With its standardized interface and easy integration capabilities, the VAS-30-1/8-SI-B simplifies system design and reduces setup time, enhancing overall efficiency in automation processes.
- 5The Festo VAS-30-1/8-SI-B is engineered to meet industry-leading quality standards, ensuring consistent performance and long service life in diverse industrial environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Suction cup height compensation | 1.9mm | Nominal width | 3mm |
| Suction cup diameter | 30mm | Suction cup volume | 1.29cm3 |
| Connection position | Top | Mounting position | Any |
| Symbol | 00991485 | Suction cup shape | Round, flat |
| Operating pressure | -13.775psi 0psi | Nominal operating pressure | -10.15psi |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III | For use in the food industry | See supplementary material information |
| Ambient temperature | -40°C 200°C | Holding force at nominal operating pressure | 31N |
| Product weight | 5g | Type of mounting | Via vacuum connection |
| Vacuum connection | G1/8 | Color | Transparent |
| Shore hardness | 60 +/- 5 | Material of screwed plug | Wrought aluminum alloy |
| Note on materials | RoHS-compliant | Suction cup material | VMQ (silicone) |
| Manufacturer ID | 1377752 |
Specifications may be subject to change without notice
