Product Model
vabv-s6-1q-g38-cb1-t5
Key Features
- 1Built with die-cast aluminum for excellent corrosion resistance (CRC 0).
- 2Equipped with G3/8 pneumatic connections for precise and reliable operation.
- 3Weighs 421 grams, ensuring robust and stable performance.
- 4Meets EU low voltage directive standards with CE marking.
- 5Manufactured with RoHS-compliant materials for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 41mm | CE marking (see declaration of conformity) | As per EU low voltage directive |
| Corrosion resistance class (CRC) | 0 - No corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 421g | Pneumatic connection 1 | G3/8 |
| Pneumatic connection 3 | G3/8 | Note on materials | RoHS-compliant |
| Plate material | Die-cast aluminum | Manufacturer ID | 8068609 |
Specifications may be subject to change without notice
