Product Model
vabm-b10-25-g12-7-p53
Key Features
- 1Ideal for complex pneumatic systems with multiple valve configurations.
- 2Ensures durability in various industrial environments.
- 3Meets European Union's Restriction of Hazardous Substances regulations.
- 4Flexible installation options for easy integration.
- 5Compact design for efficient use of space in manufacturing setups.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width dimension | 27.5mm | Mounting position | Any |
| Max. no. of valve positions | 7 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 668g |
| Type of mounting | With mounting bracket | Pneumatic connection 1 | G1/2 |
| Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
| Manufacturer ID | 8026224 |
Specifications may be subject to change without notice
