Product Model
vabm-b10-20-g38-7-p53
Key Features
- 1Supports up to 7 pneumatic valve positions for versatile application use.
- 2Classified as CRC 2, offering moderate corrosion stress resistance.
- 3Made from wrought aluminum alloy for durability and reliability.
- 4Equipped with a G3/8 pneumatic connection for easy integration.
- 5Can be mounted in any position, enhancing flexibility in installation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width dimension | 22mm | Mounting position | Any |
| Max. no. of valve positions | 7 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 437g |
| Type of mounting | With mounting bracket | Pneumatic connection 1 | G3/8 |
| Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
| Manufacturer ID | 576368 |
Specifications may be subject to change without notice
