Product Model
qspllkg18-5/16-u
Key Features
- 1The Festo DSBC Series pneumatic cylinder is designed for high-precision automation applications, ensuring reliable performance and long-lasting durability.
- 2Meets ISO 15552 standards, ensuring compatibility with various industrial automation systems.
- 3Operates effectively between -20°C and +80°C, making it suitable for a variety of environmental conditions.
- 4Equipped with air cushioning, providing smooth and controlled movement in your automation processes.
- 5With dimensions of 577.8 x 64 x 64 mm, this cylinder is compact and easy to integrate into your system.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Standard | Nominal width | 5.2mm |
| Mounting position | Any | Design | L-shape, long |
| Pack size | 10 | Structural design | Push-pull principle |
| Operating pressure for entire temperature range | -13.775psi 145psi | Maritime classification | See certificate |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -5°C 60°C | Product weight | 8.1g |
| Type of mounting | Mounting pin | Pneumatic connection 1 | Cartridge 18 mm |
| Pneumatic connection 2 | for pneumatic tubing outside diameter 5/16" | Ambient temperature Fahrenheit | 23°F 140°F |
| Releasing ring color | Gray | Note on materials | RoHS-compliant |
| Housing material | PA-reinforced | Releasing ring material | POM |
| Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
| Manufacturer ID | 132952 |
Specifications may be subject to change without notice
