Product Model
mf-ld-230ac
Key Features
- 1The Festo MF-LD-230AC illuminating seal features a clear LED switching position indicator, ensuring easy visibility in automation systems.
- 2This seal is specifically designed for mounting on solenoid valves via an M3 central screw, providing a secure and reliable connection.
- 3With a nominal operating voltage of 230 V AC and immunity to surges up to 4 kV, the MF-LD-230AC is built to withstand demanding electrical environments.
- 4The seal has a protective conductor connection available, enhancing safety and compliance with EU Low Voltage Directive and UK regulations for electrical equipment.
- 5The MF-LD-230AC is constructed from TPE-U(PU) material, ensuring durability and resistance to various environmental conditions, with an ambient temperature range of -25 °C to 85 °C.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Switching position indication | LED | Type of mounting | On air solenoid valve with M3 central screw |
| Product weight | 1.6g | Electrical connection | Form B Rectangular design MSF |
| Nominal operating voltage AC | 230V | Surge resistance | 4kV |
| Protective earth connection | Available | Nominal power luminous seal | 0.33W |
| Permissible voltage fluctuations | +/- 10 % | Degree of protection | IP65 |
| Ambient temperature | -25°C 85°C | CE marking (see declaration of conformity) | As per EU low voltage directive |
| UKCA marking (see declaration of conformity) | To UK instructions for electrical equipment | LABS (PWIS) conformity | VDMA24364-B2-L |
| Contamination level | 3 | Housing material | TPE-U(PU) |
| Color | Transparent | Manufacturer ID | 19144 |
Specifications may be subject to change without notice
