Product Model
esg-8
Key Features
- 1Antistatic Design: Ensures safe handling of sensitive materials.
- 2Vertical Mounting: Convenient and space-efficient installation.
- 3Wide Application Range: Suitable for various industrial tasks and surfaces.
- 4High Corrosion Resistance: Low CRC class for durability in harsh environments.
- 5Compact Suction Cup: 8 mm diameter for precise and gentle gripping.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Suction cup diameter | 8mm | Mounting position | Vertical |
| Special features | Anti-static | Structural design | Vacuum connection at top Vacuum connection at side with height compensation with long height compensation |
| Classification of suction cup holder | Size 2 | Suction cup shape | Round, flat |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Ambient temperature | -30°C 200°C | Vacuum connection | M5 M10x1 QS-6 PK-4 |
| Note on materials | RoHS-compliant | Suction cup material | BR FPM NBR PUR VMQ (silicone) |
| Manufacturer ID | 189170 |
Specifications may be subject to change without notice
