CKD Corporation

"CKD SC-32A speed controller: Large bore size, precise control, and reliable performance. Ideal for industrial applications requiring efficient air flow management."

The CKD SC-25A speed controller is designed for precise control in industrial applications. With a port size of 1 inch and a cylinder bore size of Φ140 to Φ250, it provides reliable performance and efficient flow management. Suitable for a wide range of industries, this speed controller ensures smooth operation and optimal results.

The CKD SC3W-15-10 speed controller elbow is designed for flexible piping direction and includes a low-speed option, making it ideal for controlling devices with lower flow rates that require fine adjustment.

The CKD SC3W-6-4 is a one-touch speed controller designed for compressed air applications. It offers precise control with a working pressure range of 0.05 MPa to 1.0 MPa and a proof pressure of 1.5 MPa. Compatible with temperatures from 5°C to 60°C, this controller features a R1/8 port size and is ideal for various industrial automation needs.

The CKD DSC-S1-06-H44 is a precision speed controller designed for filling applications. It offers linear flow characteristics, compact size, and precise adjustments, making it a reliable choice for various industrial needs.

The CKD SC3U-15-10 universal speed controller features a 360° adjustable piping direction, flame-resistant resin, and a coated piping screw for improved safety and reliability. Suitable for diverse applications where precise speed control is essential.

The CKD SC-40A speed controller is designed for large bore sizes, providing precise control with a 1 1/2 inch port size and an adjustable dial that prevents dislocation. Suitable for various industrial applications, it ensures reliable and efficient operation.

The CKD SC-50A speed control valve is designed for high-precision air flow regulation, featuring a maximum working pressure of 1.0 MPa and a flow rate of 97,000 liters per minute (ANR) at 0.5 MPa. It is suitable for various industrial applications, ensuring reliable and efficient operation.

CKD SC3W-8-6 Speed Controller: Precision air flow control with push-in fitting, 1/4" port size, and operating temperature range of 5°C to 60°C.

Short Description: The CKD SC3U-10-8 universal elbow push-to-connect valve provides a flow rate of 270 l/min, ensuring efficient fluid control in industrial settings. Made from flame-resistant PBT, it operates within 0.05 to 1 MPa pressure range.

The CKD SC3W-M5-4 speed controller elbow offers a quick-connect fitting and flexible piping direction, making it perfect for fine speed cylinders and applications requiring precise flow rate adjustment. It features flame-resistant resin parts, ensuring safety in various industrial settings.

The CKD SC3W-10-6 speed controller elbow is designed for fine flow control in pneumatic systems. It features a push-in fitting, flexible piping direction, and is made with flame-resistant materials. Perfect for devices requiring low flow rates, this elbow ensures precise adjustment and reliability.

The CKD SC3U-8-6 universal speed controller is designed with a quick-connect fitting, ensuring easy installation and operation. It features a flow rate of 270 l/min, operates within 0.05~1 MPa, and is constructed from flame-resistant PBT, making it suitable for a wide range of applications.

CKD SC3U-6-4: Universal elbow push-to-connect with 270 l/min flow rate, 360° piping direction, and flame retardant resin. Suitable for compressed air applications with 0.05 to 1 MPa operating pressure and 0 to 60°C temperature range.

The CKD SC-20A speed controller provides precise flow control with a 3/4" port size, suitable for applications requiring high accuracy. Ideal for large bore sizes from Φ100 to Φ200, this valve ensures reliable performance and easy adjustment.

The CKD SC3W-M3-4 speed control valve is a high-performance, one-touch speed controller designed for compressed air applications. It features a maximum working pressure of 1.0 MPa and operates within a fluid temperature range of 5°C to 60°C, making it suitable for a wide range of industrial settings.

The CKD SCL2-N-08-H66-300 speed control valve provides four stages of flow adjustment (13, 50, 150, and 300/min at 0.5 MPa), ensuring precise control in pneumatic systems. It features quick connection and push-in joints for easy installation.

The CKD SC3P-10-6 universal elbow push to connect flow control valve provides flexible piping direction and low speed options, ideal for fine adjustment and control of devices with lower flow rates. Flame-resistant and adjustable.

The CKD SCD2-10-H88 Speed Control Valve offers precise flow control with quick-connect fittings, perfect for a variety of applications. It ensures reliable performance and efficient operation, making it an essential component in many systems.

The CKD SCD2-06-H66 is a meter-in/meter-out speed controller that controls both air intake and exhaust flow. It is designed for remote or central actuator control and ensures stable speed, preventing actuator popping. Compatible with Φ6 and Φ8 tubing diameters, it offers fine speed control and is suitable for clean room applications.
