Product Model
810-900/000-001
Key Features
- 1High reliability for critical applications
- 2Efficient performance with minimal downtime
- 3Easy integration with various automation systems
- 4Robust design for harsh environments
- 5Long-lasting durability with minimal maintenance
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Solid conductor | 0.08 … 2.5?mm2?/ 28 … 12?AWG | Connectable sheathed cable diameter | 6 … 14?mm |
| Connection point (other) designation | Drop cables | Connection point (other) connection technology | CAGE CLAMP? |
| Width | 125?mm?/ 4.921?inches | Depth | 125?mm?/ 4.921?inches |
| Fire load | 0.632MJ | Weight | 418.8g |
| Housing | With cable entry holes | Housing protection type | IP65/NEMA 4 |
| eCl@ss 10.0 | 27-14-11-92 | eCl@ss 9.0 | 27-14-44-32 |
| ETIM 9.0 | EC000635 | ETIM 8.0 | EC000635 |
| ECCN | EAR99 | PU (SPU) | 1?pcs |
| Packaging type | Foil | Country of origin | US |
| GTIN | 4050821750451 | Customs tariff number | 8536904000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
