Product Model
793-501/000-002
Key Features
- 1Yellow Snap-On Design: Easy to install and durable.
- 2100 Labels per Card: Convenient for labeling multiple terminal blocks.
- 3Plain Marking: Ideal for clear and simple identification.
- 45mm Marker Width: Compatible with 5mm-wide terminal blocks.
- 5ROHS Compliant: Meets international safety standards for electrical components.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | plotting | Marking | plain |
| Delivery form | Marker card | Delivery form configuration | 10 strips with 10 markers per card |
| Flammability class per UL94 | V2 | Marker/strip width | 5?mm |
| Marker width | 5mm | Smear resistance | EN 60998-1:2004 |
| Color | yellow | UV resistance | EN 60068-2-5:2010 Procedure B |
| Halogen-free | Yes | Weight | 9g |
| Fire load | 0.27MJ | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-14-11-37 | eCl@ss 9.0 | 27-14-11-37 |
| ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 50?(5)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332639576 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
