Product Model
791-111
Key Features
- 1Compatible with conductors 5-11mm in diameter.
- 217mm wide and 47mm high for secure fit.
- 3Compliant with RoHS regulations for environmental safety.
- 4Easy push-in termination for quick connections.
- 5Ideal for household and building installations per EN 60998 approval.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Safety information | Cannot be used for connecting ground conductors! | Weight | 27.2g |
| Material | Brass | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-14-11-50 | eCl@ss 9.0 | 27-14-11-50 |
| ETIM 9.0 | EC002020 | ETIM 8.0 | EC002020 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 50?pcs |
| Packaging type | box | Country of origin | CH |
| GTIN | 4045454007614 | Customs tariff number | 8536904000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
