Product Model
770-100
Key Features
- 1High-quality copper contacts ensure reliable connections.
- 2Easy-to-use screwless spring pressure connection technology.
- 3Compact design fits in tight spaces, reducing installation time.
- 4Durable and resistant to vibration and environmental factors.
- 5Compatible with a wide range of applications including automation and control systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note (material data) | Information on material specifications can be found here | Color | orange |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.839MJ | Weight | 28g |
| Processing temperature | -5 … +40?°C | Continuous operating temperature | -35 … +85?°C |
| Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C | Product Group | 20 (Winsta) |
| eCl@ss 10.0 | 27-44-06-92 | eCl@ss 9.0 | 27-44-06-92 |
| ETIM 9.0 | EC002863 | ETIM 8.0 | EC002863 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 20?(1)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332819787 | Customs tariff number | 8536904000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
