Product Model
769-318
Key Features
- 11.1 mm thick, ensuring robust performance in various applications.
- 2Designed with CAGE CLAMP technology for secure and stable connections.
- 3Push-in termination of solid and ferruled conductors simplifies wiring.
- 4Compact dimensions (24.1 mm depth, 87.2 mm height) for efficient use in control cabinets.
- 50.062 MJ fire load rating for safety in harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 1.1?mm?/ 0.043?inches | Height | 87.2?mm?/ 3.433?inches |
| Depth | 24.1?mm?/ 0.949?inches | Note (material data) | Information on material specifications can be found here |
| Color | orange | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.062MJ | Weight | 2g |
| Product Group | 18 (X-COM-System) | eCl@ss 10.0 | 27-14-11-33 |
| eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
| ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?(25)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4017332968898 |
| Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
