Product Model
742-152
Key Features
- 1Secure Connections: The WAGO 742-152 terminal block ensures reliable connections with its CAGE CLAMP technology, which adjusts automatically to conductor cross-sections.
- 2Corrosion Resistance: Inherently corrosion-resistant contact materials and stainless-steel CAGE CLAMP prevent degradation from corrosive gases.
- 3Vibration-Resistant: Designed to withstand vibrations, eliminating the risk of loose connections in applications like ship installations.
- 4Easy Maintenance: No need for routine maintenance; the CAGE CLAMP connection technology provides a secure connection without damage to conductors.
- 5Universal Compatibility: Suitable for various applications including power generation, distribution, and railway traffic with a wide range of conductor sizes (0.25–1.5 mm²).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 1.5?mm?/ 0.059?inches | Height | 23.2?mm?/ 0.913?inches |
| Depth | 53.2?mm?/ 2.094?inches | Mounting type | snap-on type |
| Note (material data) | Information on material specifications can be found here | Color | gray |
| Material group | I | Insulation material (main housing) | Polyamide (PA66) |
| Flammability class per UL94 | V0 | Fire load | 0.061MJ |
| Weight | 2g | Product Group | 4 (Printed Circuit Connectors) |
| eCl@ss 10.0 | 27-44-04-92 | eCl@ss 9.0 | 27-44-04-92 |
| ETIM 9.0 | EC000886 | ETIM 8.0 | EC000886 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 300?(100)?pcs |
| Packaging type | box | Country of origin | CH |
| GTIN | 4017332412520 | Customs tariff number | 8538906000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
