Product Model
706-2300/201-300
Key Features
- 18 Digital Outputs: Connect and control multiple devices with ease.
- 23 Meter Length: Convenient for various industrial automation setups.
- 30.14 mm² Conductor Cross-Section: Ensures reliable and efficient signal transmission.
- 4DIN 41651 10-Pin Female Connectors: Easy integration with Siemens S7-300 systems.
- 5IP20 Rating: Provides protection against solid objects and dust, ensuring safe operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note | When using more than 10 wires, the maximum current per wire must be reduced to 0.7?A. | Inputs/outputs | 8 digital outputs |
| Operating voltage | ≤?AC/DC?35?V | Current per wire (max.) | 1A |
| Cable type | LiYY | Color code | per DIN VDE 47100 |
| Cable length | 3m | Weight | 179g |
| Ambient temperature (operation) | -20 … +50 °C | Product Group | 30 (WAGO France) |
| eCl@ss 10.0 | 27-24-22-20 | eCl@ss 9.0 | 27-24-22-20 |
| ETIM 9.0 | EC000237 | ETIM 8.0 | EC000237 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
| Packaging type | not specified | Country of origin | FR |
| GTIN | 4045454978860 | Customs tariff number | 85444290900 |
| RoHS Compliance Status | Compliant,No Exemption | Siemens S7-300 | 6ES7 322-1BF01-0AA0 |
| Pluggable connector | Pluggable connector per DIN 41651; female connector | Connection type 1 | System |
| Wire cross-section | 0.14mm2 | Connector 2 | Siemens 6ES7-392-1BJ00-0AA0 |
| Pole number (2) | 10 | Connection type 2 | System |
Specifications may be subject to change without notice
