Product Model
284-332
Key Features
- 1High-Quality Material: Made from durable, grey-colored material.
- 2Efficient Separation: Designed to effectively separate and organize wiring in industrial settings.
- 3Compact Size: Measures 40 mm in height, 62 mm in length, and 2 mm in width.
- 4Easy Installation: Simple to integrate into existing wiring systems.
- 52-Year Warranty: Backed by a comprehensive 2-year warranty from WAGO.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 2?mm?/ 0.079?inches | Height | 62?mm?/ 2.441?inches |
| Depth | 40?mm?/ 1.575?inches | Note (material data) | Information on material specifications can be found here |
| Color | gray | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.123MJ | Weight | 4.1g |
| Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
| eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
| ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?(25)?pcs | Packaging type | box |
| Country of origin | CN | GTIN | 4017332286817 |
| Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
