Product Model
280-438
Key Features
- 1Protects users from electrical shocks with its insulating material.
- 2Ensures secure and reliable connections with male and female connectors.
- 3Meets high standards with a fire load of 0.915 MJ, ensuring durability in harsh environments.
- 4Dimensions of 5.91 inches in depth make it ideal for various applications.
- 5Meets environmental standards, ensuring eco-friendly use in electrical operations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Number of spacings | 8-way | Depth | 150?mm?/ 5.91?inches |
| Pin spacing | 5/5.08?mm | Suitable | for male and female connectors with CAGE CLAMP?connection |
| Color | white | Flammability class per UL94 | HB |
| Fire load | 0.974MJ | Weight | 32.5g |
| Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-92 |
| eCl@ss 9.0 | 27-14-11-92 | ETIM 9.0 | EC002848 |
| ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 30?(1)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4017332277334 |
| Customs tariff number | 8205595560 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
