Product Model
231-907
Key Features
- 17-Way Insulated Jumper Bar: Designed for conductor entry with 7 poles, ensuring secure connections.
- 2Industry-Proven Technology: Utilizes spring pressure connection technology for fast, vibration-proof, and maintenance-free connections.
- 3Versatile Compatibility: Suitable for male and female connectors with 5 mm pin spacing, meeting high standards of performance and safety.
- 4High-Temperature Range: Operates within a limit temperature range of -60°C to +100°C, suitable for demanding environments.
- 5Compliant with Industrial Standards: Meets UL94 V0 flammability class and is ROHS compliant, ensuring optimal functionality and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Pin spacing | 5/5.08?mm?/ 0.197/0.2?inches | Width | 35.3?mm?/ 1.39?inches |
| Depth | 6.15?mm?/ 0.242?inches | Jumper assignment | 1-2-3-4-5-6-7 |
| Suitable | for male and female connectors with CAGE CLAMP?connection | Note (material data) | Information on material specifications can be found here |
| Color | gray | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.017MJ | Weight | 1.8g |
| Product Group | 3 (Multi Conn. System) | eCl@ss 10.0 | 27-14-11-40 |
| eCl@ss 9.0 | 27-14-11-40 | ETIM 9.0 | EC000489 |
| ETIM 8.0 | EC000489 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?(25)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4045454565862 |
| Customs tariff number | 8536698000 | RoHS Compliance Status | Compliant,No Exemption |
| Ratings per | IEC/EN 60664-1 | Rated voltage (III/2) | 320V |
| Rated surge voltage (III/2) | 4kV | Rated current | 16A |
| Legend (ratings) | (III / 2) ? Overvoltage category III / Pollution degree 2 | Number of poles | 7 |
Specifications may be subject to change without notice
