Product Model
216-425
Key Features
- 1Electro-tin plated and electrolytic copper for durability.
- 2Designed for 50mm² conductors, ensuring a secure connection.
- 3Ensures a tight seal, preventing gas leaks.
- 4Meets industry standards for electrical connections.
- 5Suitable for various electrical projects and installations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Sleeve cross-section (AWG) | 1AWG | Sleeve for | 50mm2 |
| Strip length | 30?mm?/ 1.18?inches | Length | 30mm |
| Diameter | 13mm | Diameter crimp sleeve inside | 10.3mm |
| Weight | 3.2g | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-40-02-01 | eCl@ss 9.0 | 27-40-02-01 |
| ETIM 9.0 | EC000005 | ETIM 8.0 | EC000005 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 50?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4050821134206 | Customs tariff number | 8536904000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
