Product Model
216-123
Key Features
- 1Suitable for AWG 18 and 1 mm² conductors.
- 2Features glass fiber-reinforced polyamide (PA66 GF) insulation.
- 3Simple to install with electro-tin plated contacts.
- 4Constructed with chrome-nickel spring steel (CrNi) clamping springs.
- 5Meets UL standards for safety and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Sleeve cross-section (AWG) | 18AWG | Sleeve for | 1mm2 |
| Strip length | 6?mm?/ 0.24?inches | Length | 6mm |
| Diameter | 2.5mm | Diameter crimp sleeve inside | 1.4mm |
| Color | silver-colored | Weight | 0g |
| Product Group | 2 (Terminal Block Accessories) | eCl@ss 10.0 | 27-40-02-01 |
| eCl@ss 9.0 | 27-40-02-01 | ETIM 9.0 | EC000005 |
| ETIM 8.0 | EC000005 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 5000?(1000)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4017332277648 |
| Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
