Product Model
211-835/000-002
Key Features
- 1Designed for Smart Printer, ensuring clear and precise markings on cable ties.
- 2Made from high-quality polyester, resistant to smears and UV light.
- 3Mounts seamlessly with cable ties, ensuring secure and efficient use.
- 4Compatible with standard ink ribbons (258-5005) for easy printing.
- 525 x 11 mm marking surface, suitable for various cable tie sizes.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | plain |
| Delivery form | Roll | Delivery form configuration | 500 pcs/reel; 1?line |
| Printing device | Smart Printer (thermal transfer printer) | Height | 20?mm |
| Width | 25?mm | Depth | 0.17?mm |
| Marking surface | 25 x 11?mm | Mounting type | Mounting with cable ties |
| Smear resistance | in conjunction with 258-5005 Ink Ribbon | Color | yellow |
| Material | Polyester | UV resistance | EN 60068-2-5:2010 Procedure B |
| Adhesive information | without adhesive | Halogen-free | Yes |
| Weight | 162g | Ambient temperature (storage) | +10 … +21 °C |
| Ambient temperature (operation) | -40 … +150 °C | Relative humidity | 40 … 50?% |
| ETIM 9.0 | EC001530 | ETIM 8.0 | EC001530 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
| Packaging type | bag | Country of origin | DE |
| GTIN | 4055144066340 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
