Product Model
211-821
Key Features
- 1Halogen-free material ensures safety in electrical environments.
- 24x23mm marking surface provides ample space for clear labeling.
- 3Thermal transfer marking method ensures durable and long-lasting labels.
- 4Compatible with standard ink ribbons like 258-5005 for easy use.
- 5Reel of 2,500 markers per package offers convenience and cost-effectiveness.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | plain |
| Delivery form | Roll | Delivery form configuration | 2,500 markers/reel |
| Printing device | Smart Printer (Thermal Transfer Printer) | Depth | 0.26?mm |
| Length | 23mm | Marking surface | 4 x 23?mm |
| Mounting type | Pushing in | Smear resistance | in conjunction with 258-5005 Ink Ribbon |
| Color | white | Material | Polyester |
| UV resistance | EN 60068-2-5:2010 Procedure B | Adhesive information | without adhesive |
| Halogen-free | Yes | Weight | 204g |
| Ambient temperature (storage) | +10 … +22 °C | Ambient temperature (operation) | -20 … +80 °C |
| Relative humidity | 40 … 50?% | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-40-04-01 | eCl@ss 9.0 | 27-40-06-29 |
| ETIM 9.0 | EC001530 | ETIM 8.0 | EC001530 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4050821675006 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
