Product Model
211-111
Key Features
- 1Universal application for all control cabinet marking tasks.
- 2Economical marking thanks to low purchase costs and fast printing.
- 3User-friendly WAGO Marking Software Smart Script for easy operation.
- 4Long-lasting, indelible, scratch-proof printing for durability.
- 5Fast print speed of up to 127 mm/s with recommended 50.8 mm/s for precision.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | plain |
| Delivery form | Roll | Delivery form configuration | 3000 markers/reel |
| Printing device | TP 298+ | Depth | 0.35?mm |
| Length | 12mm | Mounting type | Pushing in |
| Color | white | UV resistance | EN 60068-2-5:2010 Procedure B |
| Adhesive information | without adhesive | Halogen-free | Yes |
| Weight | 520g | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-40-06-29 | eCl@ss 9.0 | 27-40-06-29 |
| ETIM 9.0 | EC001288 | ETIM 8.0 | EC001288 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4045454486044 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
