Product Model
210-870
Key Features
- 1High-Quality Material: Made from durable polyester with a white color.
- 2Self-Adhesive Mounting: Easy to apply with a permanent adhesive.
- 3Halogen-Free: Compliant with RoHS regulations for safety.
- 4Plain Marking: Ideal for use with Smart Printers for thermal transfer printing.
- 5Compact Dimensions: 10 mm wide and 0.2 mm deep for precise labeling.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | plain |
| Delivery form | Roll | Delivery form configuration | 20 m; 1?line |
| Printing device | Smart Printer (Thermal Transfer Printer) | Width | 10?mm |
| Depth | 0.2?mm | Strip width | 10mm |
| Mounting type | Sticking | Smear resistance | in conjunction with 258-5005 Ink Ribbon |
| Color | white | Material | Polyester |
| UV resistance | EN 60068-2-5:2010 Procedure B | Adhesive information | Acrylic; permanent |
| Halogen-free | Yes | Weight | 0g |
| Ambient temperature (storage) | +10 … +21 °C | Ambient temperature (operation) | -40 … +150 °C |
| Relative humidity | 40 … 50?% | eCl@ss 10.0 | 27-40-06-29 |
| eCl@ss 9.0 | 27-40-06-29 | ETIM 9.0 | EC001288 |
| ETIM 8.0 | EC001288 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 1?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4055143378871 |
| Customs tariff number | 3919905060 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
