Product Model
210-705/000-002
Key Features
- 1High Voltage Rating: 600 VAC/VDC for reliable protection in industrial settings.
- 2CAGE CLAMP Technology: Secure and efficient connection system for conductors up to 16 mm².
- 3DIN-Rail Mounting: Easy installation on DIN-rail 35 x 15 and 35 x 7.5.
- 4Overload and Short-Circuit Protection: Up to 30 A rated current with 3 W power loss.
- 5Compliance with Safety Standards: Meets IEC/EN and UL 4248-4 approvals for enhanced safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | plain |
| Delivery form | Roll | Delivery form configuration | 3,000 labels/reel |
| Printing device | TP 298+ | Depth | 0.06?mm |
| Marking surface | 6 x 15?mm | Mounting type | Sticking |
| Color | yellow | Material | Polyester |
| Adhesive information | Acrylic; permanent | Halogen-free | Yes |
| Weight | 97.8g | Ambient temperature (storage) | +10 … +21 °C |
| Ambient temperature (operation) | -40 … +150 °C | Relative humidity | 40 … 50?% |
| eCl@ss 10.0 | 27-14-11-37 | eCl@ss 9.0 | 27-14-11-37 |
| ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4045454936662 | Customs tariff number | 3919905060 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
