Product Model
209-500/209-134
Key Features
- 1The WAGO 209-500/209-134 offers precise horizontal markings for accurate identification.
- 2Easy to use with a snap-on design, ensuring quick and secure placement.
- 3Durable white color ensures clear visibility even in harsh environments.
- 4The marking card is not stretchable, maintaining its integrity and accuracy.
- 5Suitable for various applications, including rail and chassis mount terminal blocks.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Thermal transfer | Marking | 0, 2, 4, 6, , , 0, 2, 4, 6; (5x) / 1, 3, 5, 7, , ,1, 3, 5, 7; (5x) |
| Marking direction | Horizontal marking | Marking color | black |
| Marking type | Numbers | Marking differentiation | Consecutive numbers per strip |
| Delivery form | Marker card | Delivery form configuration | 10 strips with 10 markers per card |
| Flammability class per UL94 | V2 | Marker/strip width | 5?mm |
| Marker width | 5mm | Smear resistance | EN 60998-1:2004 |
| Color | white | UV resistance | EN 60068-2-5:2010 Procedure B |
| Halogen-free | Yes | Weight | 7.8g |
| Fire load | 0.234MJ | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-14-11-37 | eCl@ss 9.0 | 27-14-11-37 |
| ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 50?(5)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332037297 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
