Product Model
2092-3602/002-000
Key Features
- 1Meets CSA standards for use in hazardous environments.
- 2Compatible with both male and female connectors.
- 3Built to last with durable materials from Germany.
- 4Simple and secure gripping mechanism for quick connections.
- 5Available in packs of 25 for convenient bulk ordering.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Pin spacing | 7.5?mm?/ 0.295?inches | Width | 22 mm |
| Design | with sliding connector release | Note (material data) | Information on material specifications can be found here |
| Color | light gray | Material group | I |
| Insulation material (main housing) | Polyphthalamide (PPA GF) | Flammability class per UL94 | V0 |
| Fire load | 0.019MJ | Weight | 0.5g |
| eCl@ss 10.0 | 27-14-11-92 | eCl@ss 9.0 | 27-14-11-92 |
| ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 100?(25)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4050821445913 | Customs tariff number | 8536698000 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
