Product Model
209-211
Key Features
- 1Precision Marking: Horizontal marking with black digits for clear identification.
- 2Snap-On Design: Easy to attach and remove from terminal blocks.
- 3Durable Construction: Not stretchable, ensuring long-lasting use.
- 4White Background: White background with black markings for high visibility.
- 5Industrial Grade: Suitable for various industrial applications with a fire load of 0.014 MJ.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Marking method | Plotting | Marking | 60 |
| Marking (number) | 10 | Marking direction | Horizontal marking |
| Marking color | black | Marking type | Numbers |
| Delivery form | Strip | Flammability class per UL94 | V2 |
| Color | white | Adhesive information | without adhesive |
| Halogen-free | Yes | Weight | 0.5g |
| Fire load | 0.014MJ | Product Group | 2 (Terminal Block Accessories) |
| eCl@ss 10.0 | 27-14-11-37 | eCl@ss 9.0 | 27-14-11-37 |
| ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 300?(10)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332096782 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
