Product Model
2091-1730/200-000
Key Features
- 1Angled Solder Pins: Designed for efficient PCB connections with angled pins for better accessibility.
- 2High Safety Standards: Meets DIN EN 61984 standards, ensuring safe operation without breaking capacity.
- 310-Pole Configuration: Suitable for multiple connections with a total of 10 poles.
- 4Black Color: Durable black finish for enhanced durability and aesthetic appeal.
- 5Durable Material: Constructed with polyphthalamide (PPA GF) insulation and electrolytic copper contacts for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Safety information | ThepicoMAX?Pluggable Connection Systemincludes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load.When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure header pins, which can be touched, are not live when unmated. | Variants: | Tape-and-reel packaging |
| Number of connection types | 1 | Number of levels | 1 |
| Pin spacing | 3.5?mm?/ 0.138?inches | Width | 36.7?mm?/ 1.445?inches |
| Height | 5.9?mm?/ 0.232?inches | Height from the surface | 3.5?mm?/ 0.138?inches |
| Depth | 10.2?mm?/ 0.402?inches | Solder pin length | 2.4mm |
| Solder pin diameter | 1mm | Plated through-hole diameter (THR) | 1.2(+0.1)mm |
| Variable coding | Yes | Anti-rotation protection | Yes |
| Contact type (pluggable connector) | Male connector/plug | Connector (connection type) | for PCB |
| Mismating protection | No | Plugging without loss of pin spacing | Yes |
| Mating direction to the PCB | 0° | Locking of plug-in connection | none |
| PCB contact | THR | Note (material data) | Information on material specifications can be found here |
| Color | black | Material group | I |
| Insulation material (main housing) | Polyphthalamide (PPA GF) | Flammability class per UL94 | V0 |
| Contact material | Electrolytic copper (ECu) | Contact plating | Tin |
| Weight | 1.3g | MSL per J-STD 020D | 1 |
| Limit temperature range | -60 … +100?°C | ETIM 9.0 | EC002637 |
| ETIM 8.0 | EC002637 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 300?pcs | Packaging type | bag |
| Country of origin | CN | GTIN | 4055143935449 |
| Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
| Ratings per | IEC/EN 60664-1 | Rated voltage (III / 3) | 160V |
| Rated impulse voltage (III / 3) | 2.5kV | Rated voltage (III/2) | 160V |
| Rated surge voltage (III/2) | 2.5kV | Nominal voltage (II/2) | 320V |
| Rated surge voltage (II/2) | 2.5kV | Rated current | 10A |
| Legend (ratings) | (III / 2) ? Overvoltage category III / Pollution degree 2 | Number of poles | 10 |
Specifications may be subject to change without notice
