Product Model
207-1433
Key Features
- 1IPX8 Certified Waterproof Protection: Ensures complete sealing against water and humidity.
- 2Silicone-Free and Label-Free: Ideal for sensitive environments, ensuring no contamination or labeling issues.
- 3Easy and Fast Installation: Simple to use, allowing immediate protection for your connectors.
- 4Reusable Design: Allows easy access for future maintenance or adjustments.
- 5Suitable for Indefinite Storage: Long-term protection without degradation, making it perfect for storage.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 57?mm?/ 2.244?inches | Height | 21.3?mm?/ 0.839?inches |
| Depth | 40.1?mm?/ 1.579?inches | Design | Size 3 |
| Mounting type | Flying leads | Protection type | IPX8 |
| Suitable | for 6 mm2 splicing connectors | Note (material data) | Information on material specifications can be found here |
| Color | gray | Housing material | Polypropylene |
| Weight | 35.4g | Ambient temperature (operation) | -55 … +85 °C |
| Ambient temperature (storage) | 0 … +40 °C | ETIM 9.0 | EC001170 |
| ETIM 8.0 | EC001170 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 24?(2)?pcs | Packaging type | Box |
| Country of origin | IT | GTIN | 4055144097306 |
| Customs tariff number | 85389099990 | RoHS Compliance Status | Compliant,No Exemption |
| Actuation type | Locking system |
Specifications may be subject to change without notice
