Product Model
2009-110/020-002
Key Features
- 1Long-lasting, indelible, scratch-proof printing.
- 2Optimized for devices and control cabinets with fabric labels and type plates.
- 3Available in various colors and sizes to suit your marking needs.
- 4Easy installation with universal application for all control cabinet marking tasks.
- 5Fast and cost-effective printing with the WAGO Thermal Transfer Smart Printer.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Suitable | for WAGO Rail-Mount Terminal Blocks TOPJOB? S, X-COM?S-SYSTEM, X-COM?S-SYSTEM-MINI and 285/788/857/2857 Series | Marking method | Thermal transfer |
| Marking | plain | Delivery form | Strip |
| Delivery form configuration | 20 m; 1?line | Printing device | Smart Printer (thermal transfer printer) |
| Width | 11?mm | Strip width | 11mm |
| Mounting type | Snapping on | Smear resistance | EN 60998-1:2004 |
| Color | yellow | Material | Polyester |
| UV resistance | EN 60068-2-5:2010 Procedure B | Adhesive information | without adhesive |
| Halogen-free | Yes | Weight | 165g |
| Ambient temperature (storage) | +10 … +21 °C | Ambient temperature (operation) | -40 … +150 °C |
| Relative humidity | 40 … 50?% | ETIM 9.0 | EC000761 |
| ETIM 8.0 | EC000761 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 1?pcs | Packaging type | bag |
| Country of origin | DE | GTIN | 4055144066197 |
| Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
