Product Model
2006-115
Key Features
- 1High-Voltage Symbol: Features a clear high-voltage symbol for enhanced safety.
- 2Black Color: Durable black color ensures visibility in various environments.
- 3Compatibility: Designed for 5 terminal blocks, ensuring seamless integration.
- 4Yellow Color Option: Available in yellow for additional visual clarity.
- 5V0 Flammability Rating: Meets V0 flammability standards for safety compliance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note (material data) | Information on material specifications can be found here | Color | yellow |
| Material group | I | Insulation material (main housing) | Polyamide (PA66) |
| Flammability class per UL94 | V0 | Fire load | 0.01MJ |
| Weight | 0.3g | Product Group | 22 (TOPJOB S) |
| eCl@ss 10.0 | 27-14-11-92 | eCl@ss 9.0 | 27-14-11-92 |
| ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 100?(25)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332002486 | Customs tariff number | 3926909990 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
