Product Model
S55176-A104
Key Features
- 1The S55176-A104 provides precise control of air dampers, valves, and other HVAC components.
- 2Equipped with a high torque output of 170 N, ensuring smooth and quiet operation.
- 3Fast response time for quick adjustments to airflow or temperature, ideal for demanding HVAC environments.
- 4Direct mounting capabilities with an M30 x 1.5 union nut simplify installation, saving time and labor costs.
- 5User-friendly design and reliable performance make it a cost-effective solution for improving HVAC system efficiency.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating Voltage | AC 230 V | Positioning Time | 50 Hz: 10 s; 60 Hz: 8.3 s |
| Positioning Signal | 2-position (SPST) | Installation Position | Vertical to 90° horizontal, do not hang |
| Power Consumption | 6 VA at 50 Hz | Lifecycle | P.M300 |
| Country of Origin | China | ECCN | EAR99 |
| AL | N | Model Number | S55176-A104 |
Specifications may be subject to change without notice
