Product Model
BPZ:SKD32.51
Key Features
- 1High Lifting Force: 1000 N lifting force for precise control.
- 2Compact Design: 20 mm stroke for efficient operation.
- 3Reliable Power Supply: 230 V AC power supply ensures consistent performance.
- 4Fail-Safe Functions: Includes emergency functions for safety.
- 5Easy Installation: Can be mounted directly on valves with no adjustment required.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating Range | None | Operating Voltage | AC 230 V |
| Positioning Time | Three-position floating point | Positioning Signal | Three-position floating point |
| Installation Position | Perpendicular to the horizontal plane | Power Consumption | 21 VA |
| Lifecycle | P.M300 | Country of Origin | Switzerland |
| ECCN | EAR99 | AL | N |
| Model | BPZ:SKD32.51 |
Specifications may be subject to change without notice
