Product Model
BPZ:MXG461.40-20
Key Features
- 1Precision Control: Offers precise control with magnetic actuators for reliable operation.
- 2Industrial Compatibility: Designed for industrial applications with PN16 and DN40 specifications.
- 3Versatile Power Options: Compatible with AC/DC 24V, DC 0/2...10 V, and 4...20 mA control signals.
- 4High Flow Rate: Features a kvs of 20 for efficient fluid handling in mixing applications.
- 5Compliance Assurance: Meets regulatory requirements under Article 33 of the REACH Regulation, ensuring safe use and disposal.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Leakage Rate | 0.02% of kvs | Bypass Leakage Rate | 0.2% of kvs |
| Operating Range | DC 0…10 V | Operating Voltage | AC 24 V; DC 24 V |
| Positioning Time | DC 0...10 V; DC 2...10 V; DC 4...20 mA | Positioning Signal | DC 0...10 V; DC 2...10 V; DC 4...20 mA |
| Installation Position | Vertical to the horizontal plane | Power Consumption | 44 VA |
| Permitted Operating Pressure | 1000 kPa | Lifecycle | P.M300 |
| Country of Origin | Switzerland | ECCN | N |
| AL | N | Model Number | BPZ:MXG461.40-20 |
Specifications may be subject to change without notice
