Product Model
7ML5725-1AA11-1AA0
Key Features
- 1Compact design for easy installation and space-saving.
- 2High integrity mechanical seal for durability and reliability.
- 3Universal power supply options available for flexibility.
- 4Adjustable sensitivity for varying material properties.
- 5Rugged design suitable for harsh conditions in the solids industry.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Backup Code | N/A | Explosion Protection Type | Dust explosion protection |
| Blade Type | Boot type, 35*106 mm | Extension Length | 100 mm |
| Process Connection Material | Aluminum alloy | Process Pressure | Up to 0.5 bar |
| Process Connection | G1-1/4 thread | Power Supply | 230V AC |
| Process Temperature | Up to 80°C | Product Series | SITRANS LPS200 |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | N | AL | N |
| Model Number | 7ML5725-1AA11-1AA0 |
Specifications may be subject to change without notice
