Product Model
7MH4950-1AA01
Key Features
- 1Connects 1 scale for precise weighing.
- 2Compatible with SIMATIC S7-300 and ET200M systems.
- 3Equipped with RS232 interface for PC connection.
- 4TTY interface for remote display connection with bus connector.
- 5Ideal for industrial weighing applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Height | 130mm | Depth | 125mm |
| Width | 40mm | Resolution | 65535 |
| Accuracy | 5.0000000000000001E-4 | Compatible PLCs | S7-300, ET 200M |
| Applications | • Hopper scales/tank scales/platform scales
• Weighing blending
• Weighing level measurement
• Tension and force measurement | Product Type | SIWAREX weighing electronic module |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | EAR99I | AL | N |
| Model | 7MH4950-1AA01 |
Specifications may be subject to change without notice
