Product Model
5SU9356-7KK50
Key Features
- 1Protects against direct and indirect contact, ensuring personnel safety.
- 2Saves space in distribution boards with a slim size of just 1MW.
- 3Operates with a breaking capacity from 4.5 kA to 10 kA, suitable for various industrial applications.
- 4Facilitates safe and easy mounting of additional components like arc fault detection devices.
- 5Meets IEC 61009-1 and IEC 61009-2-2 standards, ensuring compliance and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Description | 5SU9_A_0.03 1P+N C50 6KA; Rated Current 50A; Breaking Capacity 6KA; Trip Unit C; 1P+N; Residual Current 30mA; A; Electronic | Testing Method: (ELE: Electronic, ELM: Electromagnetic) | Electronic |
| Leakage Current Type: | A | Residual Current: | 30mA |
| Breaking Capacity Icn(kA): Standard IEC60898 | 6 | Product Type: | Residual Current Protective Circuit Breaker |
| Trip Unit: | C【C characteristic curve】 | Number of Poles: | 1P+N |
| In(A): | 50 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model Number | 5SU9356-7KK50 |
Specifications may be subject to change without notice
