Product Model
5SM9333-6
Key Features
- 1Provides reliable protection against overcurrents and short circuits.
- 2Offers high sensitivity with a rating of 30 mA for enhanced fault detection.
- 3Compact design makes it easy to integrate into various electrical systems.
- 4Meets IEC/EN 60898-1 standards for miniature circuit breakers.
- 5Suitable for both residential and industrial applications, ensuring safe power distribution.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Type | Residual Current Protection Module | Number of Poles | 3P |
| Description | 5SM9_For 5SN4 & 5SL4 RC-Unit; Rated Current 40A; 3P; Residual Current 30mA; Type A; Electronic | Detection Method (ELE electronic, ELM electromagnetic) | Electronic |
| Type of Residual Current | A | Residual Current | 30mA |
| Rated Current In(A) | 40 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | 9N9999 |
| AL | N | Model Number | 5SM9333-6 |
Specifications may be subject to change without notice
