Product Model
3SB6135-0DB40-1BA0
Key Features
- 1Complete unit combination with 22 mm plastic metalized round illuminated pushbutton.
- 2Momentary operation with flat button and holder.
- 3Integrated LED for enhanced visibility.
- 4Compatible with 110V AC/DC screw terminal.
- 5Green NO contact for reliable operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating Temperature Range | -25~+70℃ | Contact Rated Operating Current | 10A (AC-12 230V), 6A (AC-15 230V) |
| Rated Insulation Voltage | 600V | Others | None |
| Wiring Method | Screw Terminal | Operating Voltage | 110V AC |
| Illumination Type | LED | Accessory Contacts | 1NO |
| Diameter | Hole Diameter 22mm | Color | Green |
| Enclosure Material | Metallic | Operation Mode | Momentary |
| Button Type | Illuminated Flat Head Button | Type | Complete Button Set |
| Product Type | Illuminated Flat Head Button | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model Number | 3SB6135-0DB40-1BA0 |
Specifications may be subject to change without notice
