Product Model
3NP5065-1CG00
Key Features
- 1High-speed closing for quick disconnection.
- 23-pole design for reliable circuit protection.
- 3160A max current rating for heavy-duty applications.
- 4Compatible with busbar system 8US 40 mm.
- 5Clamp terminal for secure connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| DC Insulation Voltage (V): | 440 | AC Rated Voltage (V): | 690 |
| Insulation Voltage (V): | 690 | Description | 3NP5, rated current 160A, Size 00/000, 40mm busbar system clamp 3P busbar width 12mm, thickness 5mm/10mm, |
| Mounting Type: | 40mm busbar system | Fuse Rating: | Size:00/000 |
| Terminal Type: | Clamp | Other: | Busbar width 12mm, thickness 5mm/10mm, |
| Number of Poles: | 3P | In(A): | 160 |
| Specification: | 3NP50【160A】 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 3NP5065-1CG00 |
Specifications may be subject to change without notice
