Product Model
WLG8-P1131S04
Key Features
- 1High precision laser distance measurement technology for accurate data.
- 2Robust and reliable design for long-lasting performance in harsh environments.
- 3Easy integration with various industrial control systems.
- 4Compact and lightweight design for space-efficient installations.
- 5Advanced safety features for secure operation in industrial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Functional principle | Photoelectric retro-reflective sensor | Functional principle detail | Without reflector minimum distance (autocollimation/coaxial optics) |
| Dimensions (W x H x D) | 11 mm x 31 mm x 20 mm | Housing design (light emission) | Rectangular |
| Sensing range max. | 0 m ... 3 m | Sensing range | 0 m ... 1.7 m |
| Type of light | Visible red light | Light source | LED |
| Light spot size (distance) | Ø 70 mm (2 m) | Wave length | 650 nm |
| Adjustment | Potentiometer, 270° | Special feature | Detecting transparent objects |
| Special applications | Detecting transparent objects | Supply voltage UB | 10 V DC ... 30 V DC |
| Ripple | ± 10 % | Current consumption | 30 mA |
| Switching output | PNP | Switching mode | Light/dark switching |
| Switching mode selector | Selectable via light/dark rotary switch | Signal voltage PNP HIGH/LOW | Approx. V#!#– 1.8 V / 0 V |
| Output current Imax. | ≤ 100 mA | Response time | ≤ 0.5 ms |
| Switching frequency | 1,000 Hz | Attenuation along light beam | ≤ 20 % |
| Connection type | Cable with connector M8, 3-pin, 1,000 mm | Cable material | Plastic, PVC |
| Circuit protection | A7)#!#B8)#!#D9) | Weight | 50 g |
| Polarisation filter | ✔ | Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA | Enclosure rating | IP67 |
| Items supplied | Stainless steel mounting bracket (1.4305, 303) BEF-W170, Reflector P250F | Special feature | Detecting transparent objects |
| Ambient operating temperature | –25 °C ... +55 °C | Ambient temperature, storage | –40 °C ... +70 °C |
Specifications may be subject to change without notice
