Product Model
WL18X-3P930
Key Features
- 1Detects objects accurately under difficult application conditions.
- 2Constructed with high-quality materials for long-lasting performance.
- 3Suitable for various industrial applications, including proximity detection.
- 4Designed with user-friendly installation in mind, minimizing setup time.
- 5Meets EX-proof standards, ensuring safe operation in hazardous environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Functional principle | Photoelectric retro-reflective sensor | Functional principle detail | Without reflector minimum distance (autocollimation/coaxial optics) |
| Dimensions (W x H x D) | 23.6 mm x 117 mm x 49.3 mm | Housing design (light emission) | Rectangular |
| Sensing range max. | 0 m ... 7 m | Sensing range | 0 m ... 5 m |
| Focus | 1.8° | Type of light | Visible red light |
| Light source | LED | Light spot size (distance) | Ø 40 mm (2 m) |
| Angle of dispersion | 1.8° | Wave length | 645 nm |
| Adjustment | Potentiometer, 1 turn | Special applications | Explosive areas |
| Supply voltage UB | 10 V DC ... 30 V DC | Ripple | < 5 V |
| Current consumption | 40 mA | Switching output | PNP |
| Switching mode | Light/dark switching | Output current Imax. | ≤ 100 mA |
| Response time | < 500 µs | Switching frequency | 1,000 Hz |
| Connection type | Cable with M12 male connector, 4-pin, 0.29 m | Cable material | Plastic, PVC |
| Circuit protection | A7)#!#C8)#!#D9) | Weight | 300 g |
| Polarisation filter | ✔ | Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA | Enclosure rating | IP67 |
| ATEX marking | ATEX II 3G Ex nA op is IIB T4 Gc X ATEX II 3D Ex tc IIIB T135°C Dc X In accordance with directive 2014/34 / EU | Ex area category | 3D, 3G |
| Ambient operating temperature | –20 °C ... +50 °C | Ambient temperature, storage | –40 °C ... +75 °C |
Specifications may be subject to change without notice
