Product Model
WL100L-F3431S42
Key Features
- 1High-precision measurement with ±0.1% accuracy.
- 2Robust design for harsh industrial environments.
- 3Wide pressure range from 0 to 100 bar.
- 4Compact and lightweight for easy integration.
- 5Compatible with various industrial protocols.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Functional principle | Photoelectric retro-reflective sensor | Functional principle detail | With minimum distance to reflector (dual lens system) |
| Dimensions (W x H x D) | 11 mm x 31 mm x 20 mm | Housing design (light emission) | Rectangular |
| Sensing range max. | 0.08 m ... 12 m | Sensing range | 0.08 m ... 10 m |
| Type of light | Visible red light | Light source | Laser |
| Light spot size (distance) | Ø 12 mm (10 m) | Wave length | 650 nm |
| Laser class | 1 | Adjustment | Potentiometer, 270° |
| Special applications | Detecting small objects, Detection of objects moving at high speeds | Special features | Without reflector#!#Cable length 290 mm |
| Supply voltage UB | 10 V DC ... 30 V DC | Ripple | ± 10 % |
| Current consumption | 30 mA | Switching output | PNP |
| Switching mode | Light/dark switching | Switching mode selector | Selectable via light/dark rotary switch |
| Signal voltage PNP HIGH/LOW | U#!#- 1,8 V / ca. 0 V | Output current Imax. | ≤ 100 mA |
| Response time | < 0.25 ms | Switching frequency | 2,000 Hz |
| Connection type | Cable with M12 male connector, 4-pin, 290 mm | Cable material | Plastic, PVC |
| Cable diameter | Ø 0.14 mm | Circuit protection | A7)#!#B8)#!#D9) |
| Weight | 150 g | Polarisation filter | ✔ |
| Housing material | Plastic, ABS/PC | Optics material | Plastic, PMMA |
| Enclosure rating | IP65 | Items supplied | Stainless steel mounting bracket (1.4301/304) BEF-W100-A |
| Ambient operating temperature | –10 °C ... +50 °C | Ambient temperature, storage | –40 °C ... +70 °C |
Specifications may be subject to change without notice
