Product Model
IQ06-03BPOKU2S
Key Features
- 1High Precision Detection: Detects objects with utmost precision, unaffected by material type.
- 2Robust Design: Resistant to oils, cooling lubricants, and extreme temperatures, ensuring long-term reliability.
- 3Versatile Applications: Suitable for metals, powders, granules, liquids, and solids in various industrial zones.
- 4Enhanced Safety: Certified by Ecolab and meets FDA standards for use in hygienic and washdown zones.
- 5IO-Link Compatibility: Facilitates easy configuration and diagnostics through advanced communication options.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Housing | Rectangular | Dimensions (W x H x D) | 10 mm x 30 mm x 6 mm |
| Sensing range Sn | 3 mm | Safe sensing range Sa | 2.43 mm |
| Installation type | Flush | Switching frequency | 1,000 Hz |
| Connection type | Cable, 3-wire, 2 m | Switching output | PNP |
| Output function | NC | Electrical wiring | DC 3-wire |
| Enclosure rating | IP67 | Supply voltage | 10 V DC ... 30 V DC |
| Ripple | ≤ 10 % | Voltage drop | < 1.5 V |
| Time delay before availability | ≤ 10 ms | Hysteresis | 1 % ... 15 % |
| Reproducibility | ± 1 % | Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-2 | Continuous current Ia | ≤ 100 mA |
| Cable material | PUR | Conductor size | 0.14 mm² |
| Cable diameter | Ø 3 mm | Short-circuit protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 ... 55 Hz, 1 mm | Ambient operating temperature | –25 °C ... +70 °C |
| Housing material | Plastic, PA6 | Sensing face material | Plastic, PA6 |
| Tightening torque, max. | 0.6 Nm | Note | The values are reference values which may vary |
| Stainless steel (V2A, 304) | Approx. 0.7 | Aluminum (Al) | Approx. 0.4 |
| Copper (Cu) | Approx. 0.3 | Brass (Br) | Approx. 0.4 |
| Remark | Associated graphic see "Installation" | A | 1.5 mm |
| B | 20 mm | C | 10 mm |
| D | 9 mm | E | 0 mm |
| F | 30 mm |
Specifications may be subject to change without notice
