Product Model
IMB08-02BPSVQDK
Key Features
- 1Advanced 3D laser scanner for precise distance measurement.
- 2Compact design for easy integration into various industrial settings.
- 3High-resolution scanning capabilities for detailed object detection.
- 4Robust and durable construction for long-lasting performance.
- 5Compatible with SICK's extensive range of industrial sensors and software.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Housing | Metric | Housing | Short-body |
| Thread size | M8 x 1 | Diameter | Ø 8 mm |
| Sensing range Sn | 2 mm | Safe sensing range Sa | 1.62 mm |
| Installation type | Flush | Switching frequency | 4,000 Hz |
| Connection type | Cable with connector M12, 3-pin, 600 mm | Switching output | PNP |
| Output function | NO | Electrical wiring | DC 3-wire |
| Enclosure rating | IP681)#!#IP69K2) | Special features | Resistant against coolant lubricants, Visual adjustment indicator, IO-Link |
| Special applications | Zones with coolants and lubricants, Mobile machines, Difficult application conditions | Items supplied | Mounting nut, V2A stainless steel, with locking teeth (2x) |
| Supply voltage | 10 V DC ... 30 V DC | Ripple | ≤ 10 % |
| Voltage drop | ≤ 2 V | Hysteresis | 3 % ... 20 % |
| Reproducibility | ≤ 2 % | Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-2 | Continuous current Ia | ≤ 200 mA |
| No load current | ≤ 10 mA | Cable material | PUR |
| Short-circuit protection | ✔ | Power-up pulse protection | ✔ |
| Shock and vibration resistance | 100 g / 11 ms / 1000 cycles; 150 g / 1 Mio cycles; 10 Hz ... 55 Hz, 1 mm / 55 Hz ... 500 Hz / 15 g | Ambient operating temperature | –40 °C ... +80 °C |
| Housing material | Stainless steel V2A, DIN 1.4305 / AISI 303 | Sensing face material | Plastic, LCP |
| Housing length | 32 mm | Thread length | 28 mm |
| Tightening torque, max. | Typ. 7 Nm4)#!#Typ. 14 Nm5) | Protection class | III |
| UL File No. | E181493 | Communication interface | IO-Link V1.0 |
| Communication Interface detail | COM2 (38,4 kBaud) | Process data length | 1 Byte |
| Process data structure | Bit 0 = Sr reached#!#Bit 1 = Sa reached | Note | The values are reference values which may vary |
| St37 steel (Fe) | 1 | Stainless steel (V2A, 304) | Approx. 0.74 |
| Aluminum (Al) | Approx. 0.43 | Copper (Cu) | Approx. 0.33 |
| Brass (Br) | Approx. 0.46 | Remark | Associated graphic see "Installation" |
| B | 6.5 mm | C | 8 mm |
| D | 6 mm | F | 16 mm |
Specifications may be subject to change without notice
