Product Model
GTB2F-E5141
Key Features
- 1Compact design with dimensions 14 mm x 24 mm x 3.5 mm.
- 2Advanced background suppression for improved detection accuracy.
- 3Visible red light source with a light spot size of Ø 1 mm at 5 mm distance.
- 4High sensitivity with a minimum detectable object (MDO) of 0.1 mm.
- 5Long service life of up to 100,000 hours at +25 °C.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Functional principle | Photoelectric proximity sensor | Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 14 mm x 24 mm x 3.5 mm | Housing design (light emission) | Rectangular |
| Minimum detectable object (MDO) | 0.1 mm | Sensing range max. | 1 mm ... 9 mm |
| Sensing range | 1 mm ... 8 mm | Type of light | Visible red light |
| Light source | PinPoint LED | Light spot size (distance) | Ø 1 mm (5 mm) |
| Wave length | 660 nm | Adjustment | None |
| Supply voltage UB | 10 V DC ... 30 V DC | Ripple | < 5 V |
| Current consumption | 20 mA | Switching output | NPN |
| Switching mode | Dark switching | Output current Imax. | ≤ 50 mA |
| Response time | < 0.625 ms | Switching frequency | 800 Hz |
| Connection type | Cable with connector M8, 3-pin, 200 mm | Cable material | Plastic, PVC |
| Cable diameter | Ø 2.3 mm | Circuit protection | A6)#!#C7)#!#D8) |
| Weight | 13 g | Housing material | Plastic, VISTAL® |
| Optics material | Plastic, MABS | Enclosure rating | IP67 |
| Ambient operating temperature | –20 °C ... +50 °C | Ambient temperature, storage | –40 °C ... +70 °C |
| UL File No. | NRKH.E348498 & NRKH7.E348498 | Repeatability (Tanot constant) | 0.1 mm |
| Hysteresis | < 0.3 mm |
Specifications may be subject to change without notice
