Product Model
XB5AA84101
Key Features
- 1High-quality power supply module for industrial use.
- 2Reliable performance in demanding environments.
- 3Compact design for easy integration into systems.
- 4Compliant with international safety standards (e.g., UL, CE).
- 5Durable construction with long lifespan.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB5 | Product or Component Type | Manual overload reset push-button |
| Device short name | XB5 | Bezel material | Dark grey plastic |
| Fixing collar material | Plastic | Mounting diameter | 0.9 in (22 mm) |
| Shape of signaling unit head | Round | Operator profile | Red flush, O white) |
| Activating distance | 0.7…4.7 in (17…120 mm) | Device presentation | Complete product |
| Height | 1.1 in (29 mm) | Width | 1.1 in (29 mm) |
| Depth | 4.7 in (120 mm) | Net Weight | 0.060 lb(US) (0.027 kg) |
| Resistance to high pressure washer | 1015.3 psi (7000000 Pa) 131 °F (55 °C) 0.1 m | Operating travel | 0.4 in (10 mm) |
| Protective treatment | TH | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) | Electrical shock protection class | Class II IEC 60536 |
| IP degree of protection | IP66 IEC 60529 | NEMA degree of protection | NEMA 4X |
| IK degree of protection | IK03 conforming to IEC 50102 | Standards | IEC 60947-1 |
| Product Certifications | UL Listed |
Specifications may be subject to change without notice
